NARROW SLEND COTTAGE
Full construction drawings will be customized and delivered after purchase.
Project Description
Plan Details- • Narrow Slend Cottage is a design of a 2-storey minimalistic narrow residential building. The design is characterized by luxury aesthetics featuring glass and aluminium.
- • For natural light and ventilation, it features large glass windows and sliding glass doors and open spaces..
- • Narrow Slend Cottage has a design footprint of 50 square meters, and a height 7.2 meters above ground level.
- • There is an entry porch at the ground floor leading to the living room, a kitchen, and a stairway.
- • Upstairs has a master bedroom with a full bathroom and a balcony, and one other bedroom with a half bathroom.
- • Narrow Slend has a unique façade design with primary colours; off-white and light grey, and secondary colours; charcoal and dark grey.
- • Foundation Plan – Structural base layout, and footprint definition
- • Floor Plan(s) – Spatial arrangement, room dimensions, openings, and functional relationships.
- • Roof Plan – Roof form, roof pitch, drainage direction, and structural configuration.
- • Exterior Elevations – Front, rear, and side views showing façade design and material intent.
- • 3D Impressions – Exterior and interior 3D impressions with garden and furniture placements.
- • Design Detailing Notes – Wall sections, openings, structural coordination, and architectural detailing guidance.
- • Architectural or Engineering Stamp
- • Structural Engineering Calculations
- • Mechanical (HVAC) Layouts and Duct Sizing
- • Plumbing Design and Pipe Routing
- • Electrical Load Calculations and Certification
- • Local Authority Approvals / Permits
