ELYSIAN VALE RESIDENCE
Full construction drawings will be customized and delivered after purchase.
Project Description
Plan Details- • A single storey modern residence featuring open living areas and private bedroom suites.
- • Elysian Vale is a modern 4-bedroom self-contained with 198 square meters building footprint and 4.2 meters above ground level.
- • It combines a living area, dining area, and an open kitchen linearly arranged with a front porch that leads it.
- • The Elysian Vale has 3 half bathrooms, a guest WC, and a full bathroom attached to the master bedroom.
- • There is a single garage attached to the vale linked directly to the living area.
- • Elysian Vale is suitable for a singular family in a city, a town, or a cottage county.
- • Foundation Plan – Structural base layout, and footprint definition
- • Floor Plan(s) – Spatial arrangement, room dimensions, openings, and functional relationships.
- • Roof Plan – Roof form, roof pitch, drainage direction, and structural configuration.
- • Exterior Elevations – Front, rear, and side views showing façade design and material intent.
- • 3D Impressions – Exterior and interior 3D impressions with garden and furniture placements.
- • Design Detailing Notes – Wall sections, openings, structural coordination, and architectural detailing guidance.
- • Architectural or Engineering Stamp
- • Structural Engineering Calculations
- • Mechanical (HVAC) Layouts and Duct Sizing
- • Plumbing Design and Pipe Routing
- • Electrical Load Calculations and Certification
- • Local Authority Approvals / Permits
